HGM125 Ring Roller Grinding Mill Introduction Brand: Clirik Model: HGM125 Ring Roller Grinding Mill Application Materials: calcium carbonate, kaolin, clay, gypsum, carbon black, dolomite, mica, cement, limestone, marble, graphite and other more than 300 kinds of minerals powder grinding Input Size: 10-25 mm Output Size: 300-2500 mesh (75-5 um) Capacity: 1-45 T/H Application Field: mining, chemical
Brand: Clirik
Model: HGM125 Ring Roller Grinding Mill
Application Materials: calcium carbonate, kaolin, clay, gypsum, carbon black, dolomite, mica, cement, limestone, marble, graphite and other more than 300 kinds of minerals powder grinding
Input Size: 10-25 mm
Output Size: 300-2500 mesh (75-5 um)
Capacity: 1-45 T/H
Application Field: mining, chemical, cmenet, paper making, construction and other industries.
1. High powder fineness process, the powder fineness can be adjusted between 300-2500 mesh;
2. High capacity, there are 5 models dolomite powder making machine in Shanghai Clirik, the highest capacity can up to 45 t/h;
3. Environment friend, Clirik HGM dolomite powder making machine id environment friendly, it was popularity by our customers;
4. Factory price, compare with other brand, Clirik is grinding mill machine manufacurer, so we can supply our customer machines in a lower price;
5. Good after sales service, 24 hours hot line can help you relove any problems you meet.
Application Materials: calcium carbonate, kaolin, clay, gypsum, carbon black, dolomite, mica, cement, limestone, marble, graphite and other more than 300 kinds of minerals powder grinding
Application Field: mining, chemical, cmenet, paper making, construction and other industries.
Ring Diameter(mm) | Ring Number (PCS) | Roller Number(PCS) | Main Shaft Speed (r. p. min) | Input Size (mm) | Finished Size (um/mesh) | Capacity (t/h) | Outlet Size L*W*H (m) |
1250 | 4 | 30-44 | 135-155 | ≤20 | 100-2 (150-3000) | 2.5-20 | 14*9*10.25 |
Main Unit | Classifier | Blower | Crusher | Bucket Elevator | BeltConveyor Feeder | Spiral Conveyor | Discharging Valve | Air compressor |
185-200 | 37-4*15 | 2*45-2*55 | 45 | 4 | 3 | 2*3 | 2*1.1 | 2*15-37 |
| Parameters of HGM Series Ultrafine Grinding Mill | |||||||
| Model | HGM80 | HGM80A | HGM90L | HGM100L-Ⅱ | HGM100P | HGM125L | HGM1680L |
| Ring Diameter(mm) | 800 | 800 | 900 | 1000 | 1000 | 1250 | 1680 |
| Ring Number (PCS) | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| Input Size (mm) | ≤10 | ≤10 | ≤10 | ≤15 | ≤15 | ≤20 | ≤20 |
| Output Size (mesh) | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 |
| Capacity (t/h) | 0.5-5.5 | 0.5-5.5 | 0.8-6.5 | 1.2-10 | 1.2-11 | 2.5-20 | 5-45 |
| Outlet Size L*W*H (mm) | 8605*4139*6050 | 10454*3393*6626 | 11735*3952*7525 | 14507*3633*7562 | 14362*4200*7562 | 19261*4406*8591 | 25067*5414*9007 |
| Main Motor Power (kw) | 75 | 75 | 55*2 | 132/75*2 | 132/75*2 | 185 | 315 |
